Tokalar (FHC Yatay Kelepçeler)

Cephe askı sistemlerinde kullanılan FHC yatay kelepçe tokaları; EPDM contalı, alüminyum, farklı genişlik ve delik çaplarında ATK103 sistemine uygun sunulur.

Kategori Cephe Taşıyıcı & Montaj Sistemleri
Marka Fischer

Etiketler

Talep birimi: Adet

Ürün çeşidi * Miktar Birim: Adet

Hızlı teklif
Güvenilir tedarik
Geniş ürün gamı

Ürün Açıklaması

FHC tokaları, cephe askı sistemlerinde kullanılan EPDM contalı alüminyum yatay kelepçelerdir ve ATK103 sistemine uygundur. Farklı genişlik, delik çapı ve diş boyutlarında (M5, M6) çeşitleri bulunur.

Ürün Çeşitleri

Ürün No	Tanım	Sistem	Boyutlar	Genişlik	Yüksekliği (H)	Derinlik
565953	FHC 20x3 60/7/SP AL EPDM	ATK103	7 mm	60 mm	62 mm	20 mm
565951	FHC 20x3 36/7/SP AL EPDM	ATK103	7 mm	36 mm	62 mm	20 mm
565259	FHC 20x3 36/altıgen/SP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	20 mm
565257	FHC 20x2 36/altıgen/SP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	20 mm
565263	FHC 20x3 80/altıgen/SP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	20 mm
565260	FHC 20x3 60/altıgen/SP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	20 mm
565261	FHC 20x2 60/altıgen/SP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	20 mm
565264	FHC 20x2 80/altıgen/SP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	20 mm
545579	FHC 20x2 36/6,5/SP AL	ATK103	6.5 mm	36 mm	62 mm	20 mm
547533	FHC 20x2 60/6,5/SP AL	ATK103	6.5 mm	60 mm	62 mm	20 mm
565244	FHC 20x2 80/6,5/SP AL	ATK103	6.5 mm	80 mm	62 mm	20 mm
565249	FHC 20x3 36/6,5/SP AL	ATK103	6.5 mm	36 mm	62 mm	20 mm
547543	FHC 20x3 60/6,5/SP AL	ATK103	6.5 mm	60 mm	62 mm	20 mm
565251	FHC 20x3 80/6,5/SP AL	ATK103	6.5 mm	80 mm	62 mm	20 mm
565258	FHC 20x2 36/6,5/SP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	20 mm
565262	FHC 20x2 60/6,5/SP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	20 mm
565265	FHC 20x2 80/6,5/SP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	20 mm
565284	FHC 20x3 60/6,5/SP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	20 mm
565282	FHC 20x3 36/6,5/SP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	20 mm
565286	FHC 20x3 80/6,5/SP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	20 mm
565243	FHC 20x2 36/9/SP AL	ATK103	9 mm	36 mm	62 mm	20 mm
547537	FHC 20x2 60/9/SP AL	ATK103	9 mm	60 mm	62 mm	20 mm
547545	FHC 20x3 60/9/SP AL	ATK103	9 mm	60 mm	62 mm	20 mm
565250	FHC 20x3 36/9/SP AL	ATK103	9 mm	36 mm	62 mm	20 mm
565245	FHC 20x2 80/9/SP AL	ATK103	9 mm	80 mm	62 mm	20 mm
565252	FHC 20x3 80/9/SP AL	ATK103	9 mm	80 mm	62 mm	20 mm
565961	FHC 20x3 80/8,5/SP AL EPDM	ATK103	8,5 mm	80 mm	62 mm	20 mm
565957	FHC 20x3 36/8,5/SP AL EPDM	ATK103	8,5 mm	36 mm	62 mm	20 mm
565281	FHC 20x3 36/kare/SP AL	ATK103	9.2 mm	36 mm	62 mm	20 mm
565283	FHC 20x3 60/kare/SP AL	ATK103	9.2 mm	60 mm	62 mm	20 mm
565285	FHC 20x3 80/kare/SP AL	ATK103	9.2 mm	80 mm	62 mm	20 mm
565325	FHC 30x3 36/altıgen/SP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	30 mm
565326	FHC 30x3 60/altıgen/SP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	30 mm
565323	FHC 30x2 36/altıgen/SP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	30 mm
565329	FHC 30x3 80/altıgen/SP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	30 mm
565327	FHC 30x2 60/altıgen/SP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	30 mm
565330	FHC 30x2 80/altıgen/SP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	30 mm
548288	FHC 30x2 36/6,5/SP AL	ATK103	6.5 mm	36 mm	62 mm	30 mm
547539	FHC 30x2 60/6,5/SP AL	ATK103	6.5 mm	60 mm	62 mm	30 mm
548020	FHC 30x2 80/6,5/SP AL	ATK103	6.5 mm	80 mm	62 mm	30 mm
548013	FHC 30x3 36/6,5/SP AL	ATK103	6.5 mm	36 mm	62 mm	30 mm
547181	FHC 30x3 60/6,5/SP AL	ATK103	6.5 mm	60 mm	62 mm	30 mm
548027	FHC 30x3 80/6,5/SP AL	ATK103	6.5 mm	80 mm	62 mm	30 mm
565324	FHC 30x2 36/6,5/SP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	30 mm
565348	FHC-H 30x3 36/6,5/SP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	30 mm
565328	FHC 30x2 60/6,5/SP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	30 mm
565350	FHC-H 30x3 60/6,5/SP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	30 mm
565331	FHC 30x2 80/6,5/SP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	30 mm
565346	FHC-H 30x3 80/6,5/SP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	30 mm
548289	FHC 30x2 36/9/SP AL	ATK103	9 mm	36 mm	62 mm	30 mm
548014	FHC 30x3 36/9/SP AL	ATK103	9 mm	36 mm	62 mm	30 mm
547541	FHC 30x2 60/9/SP AL	ATK103	9 mm	60 mm	62 mm	30 mm
547550	FHC 30x3 60/9/SP AL	ATK103	9 mm	60 mm	62 mm	30 mm
548021	FHC 30x2 80/9/SP AL	ATK103	9 mm	80 mm	62 mm	30 mm
548031	FHC 30x3 80/9/SP AL	ATK103	9 mm	80 mm	62 mm	30 mm
565347	FHC 30x3 36/kare/SP AL	ATK103	9.2 mm	36 mm	62 mm	30 mm
565349	FHC 30x3 60/kare/SP AL	ATK103	9.2 mm	60 mm	62 mm	30 mm
565345	FHC 30x3 80/kare/SP AL	ATK103	9.2 mm	80 mm	62 mm	30 mm
565266	FHC 20x2 36/altıgen/FP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	20 mm
565268	FHC 20x3 36/altıgen/FP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	20 mm
565270	FHC 20x2 60/altıgen/FP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	20 mm
565269	FHC 20x3 60/altıgen/FP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	20 mm
565273	FHC 20x2 80/altıgen/FP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	20 mm
565272	FHC 20x3 80/altıgen/FP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	20 mm
565246	FHC 20x2 36/6,5/FP AL	ATK103	6.5 mm	36 mm	62 mm	20 mm
565253	FHC 20x3 36/6,5/FP AL	ATK103	6.5 mm	36 mm	62 mm	20 mm
547532	FHC 20x2 60/6,5/FP AL	ATK103	6.5 mm	60 mm	62 mm	20 mm
547542	FHC 20x3 60/6,5/FP AL	ATK103	6.5 mm	60 mm	62 mm	20 mm
545570	FHC 20x2 80/6,5/FP AL	ATK103	6.5 mm	80 mm	62 mm	20 mm
565255	FHC 20x3 80/6,5/FP AL	ATK103	6.5 mm	80 mm	62 mm	20 mm
565271	FHC 20x2 60/6,5/FP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	20 mm
565278	FHC 20x3 60/6,5/FP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	20 mm
565274	FHC 20x2 80/6,5/FP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	20 mm
565280	FHC 20x3 80/6,5/FP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	20 mm
565267	FHC 20x2 36/6,5/FP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	20 mm
565276	FHC 20x3 36/6,5/FP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	20 mm
565247	FHC 20x2 36/9/FP AL	ATK103	9 mm	36 mm	62 mm	20 mm
565254	FHC 20x3 36/9/FP AL	ATK103	9 mm	36 mm	62 mm	20 mm
547536	FHC 20x2 60/9/FP AL	ATK103	9 mm	60 mm	62 mm	20 mm
547544	FHC 20x3 60/9/FP AL	ATK103	9 mm	60 mm	62 mm	20 mm
565248	FHC 20x2 80/9/FP AL	ATK103	9 mm	80 mm	62 mm	20 mm
565256	FHC 20x3 80/9/FP AL	ATK103	9 mm	80 mm	62 mm	20 mm
565275	FHC 20x3 36/kare/FP AL	ATK103	9.2 mm	36 mm	62 mm	20 mm
565277	FHC 20x3 60/kare/FP AL	ATK103	9.2 mm	60 mm	62 mm	20 mm
565279	FHC 20x3 80/kare/FP AL	ATK103	9.2 mm	80 mm	62 mm	20 mm
565332	FHC 30x2 36/altıgen/FP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	30 mm
565334	FHC 30x3 36/altıgen/FP AL EPDM	ATK103	10.2 mm	36 mm	62 mm	30 mm
565336	FHC 30x2 60/altıgen/FP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	30 mm
565335	FHC 30x3 60/altıgen/FP AL EPDM	ATK103	10.2 mm	60 mm	62 mm	30 mm
565339	FHC 30x2 80/altıgen/FP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	30 mm
565338	FHC 30x3 80/altıgen/FP AL EPDM	ATK103	10.2 mm	80 mm	62 mm	30 mm
548010	FHC 30x2 36/6,5/FP AL	ATK103	6.5 mm	36 mm	62 mm	30 mm
548015	FHC 30x3 36/6,5/FP AL	ATK103	6.5 mm	36 mm	62 mm	30 mm
547538	FHC 30x2 60/6,5/FP AL	ATK103	6.5 mm	60 mm	62 mm	30 mm
547180	FHC 30x3 60/6,5/FP AL	ATK103	6.5 mm	60 mm	62 mm	30 mm
548025	FHC 30x2 80/6,5/FP AL	ATK103	6.5 mm	80 mm	62 mm	30 mm
548032	FHC 30x3 80/6,5/FP AL	ATK103	6.5 mm	80 mm	62 mm	30 mm
565333	FHC 30x2 36/6,5/FP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	30 mm
565337	FHC 30x2 60/6,5/FP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	30 mm
565340	FHC 30x2 80/6,5/FP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	30 mm
565344	FHC-H 30x3 60/6,5/FP AL EPDM	ATK103	6.5 mm	60 mm	62 mm	30 mm
565342	FHC-H 30x3 36/6,5/FP AL EPDM	ATK103	6.5 mm	36 mm	62 mm	30 mm
565352	FHC-H 30x3 80/6,5/FP AL EPDM	ATK103	6.5 mm	80 mm	62 mm	30 mm
548012	FHC 30x2 36/9/FP AL	ATK103	9 mm	36 mm	62 mm	30 mm
548019	FHC 30x3 36/9/FP AL	ATK103	9 mm	36 mm	62 mm	30 mm
547540	FHC 30x2 60/9/FP AL	ATK103	9 mm	60 mm	62 mm	30 mm
547546	FHC 30x3 60/9/FP AL	ATK103	9 mm	60 mm	62 mm	30 mm
548026	FHC 30x2 80/9/FP AL	ATK103	9 mm	80 mm	62 mm	30 mm
548033	FHC 30x3 80/9/FP AL	ATK103	9 mm	80 mm	62 mm	30 mm
565343	FHC 30x3 60/kare/FP AL	ATK103	9.2 mm	60 mm	62 mm	30 mm
565341	FHC 30x3 36/kare/FP AL	ATK103	9.2 mm	36 mm	62 mm	30 mm
565351	FHC 30x3 80/kare/FP AL	ATK103	9.2 mm	80 mm	62 mm	30 mm
565962	FHC 20x3 36/7/FP AL	ATK103	7 mm	36 mm	62 mm	20 mm
565964	FHC 20x3 60/7/FP AL	ATK103	7 mm	60 mm	62 mm	20 mm
565966	FHC 20x3 80/7/FP AL	ATK103	7 mm	80 mm	62 mm	20 mm
521662	BR-VS 50-F	System One	—	50 mm	132 mm	15 mm
521663	BR-VS 50-S	System One	—	50 mm	132 mm	15 mm
018439	FHC-BSL 18x2 40/6.5/F-SP AL	System One	6 mm	40 mm	56 mm	18 mm
565963	FHC 20x3 36/7/SP AL	ATK103	7 mm	36 mm	62 mm	20 mm
565950	FHC 20x3 36/7/FP AL EPDM	ATK103	7 mm	36 mm	62 mm	20 mm
565956	FHC 20x3 36/8,5/FP AL EPDM	ATK103	8,5 mm	36 mm	62 mm	20 mm
048904	BR-BS M6/50	System One	6 mm	50 mm	65 mm	30 mm
018448	FHC-BSL 18x2 40/9/F-SP AL	System One	8 mm	40 mm	56 mm	18 mm
565965	FHC 20x3 60/7/SP AL	ATK103	7 mm	60 mm	62 mm	20 mm
565952	FHC 20x3 60/7/FP AL EPDM	ATK103	7 mm	60 mm	62 mm	20 mm
565960	FHC 20x3 80/8,5/FP AL EPDM	ATK103	8,5 mm	80 mm	62 mm	20 mm
091536	BR-BS M6/100	System One	6 mm	100 mm	65 mm	30 mm
018447	FHC-BSL 18x2 90/9/F-SP AL	System One	8 mm	90 mm	56 mm	18 mm
049238	BR-BS M8/50	System One	8 mm	50 mm	65 mm	30 mm
565967	FHC 20x3 80/7/SP AL	ATK103	7 mm	80 mm	62 mm	20 mm
565954	FHC 20x3 80/7/FP AL EPDM	ATK103	7 mm	80 mm	62 mm	20 mm
078585	BR-BS M8/100	System One	8 mm	100 mm	65 mm	30 mm
078587	BR-BS M8/150	System One	8 mm	150 mm	65 mm	30 mm
565955	FHC 20x3 80/7/SP AL EPDM	ATK103	7 mm	80 mm	62 mm	20 mm
565958	FHC 20x3 60/8,5/FP AL EPDM	ATK103	8,5 mm	60 mm	62 mm	20 mm
565959	FHC 20x3 60/8,5/SP AL EPDM	ATK103	8,5 mm	60 mm	62 mm	20 mm

Teknik Özellikler

Teknik özellikler
Onay	DoP: BWM-LE-005
Onay	DoP: BWM-LE-006
Onay	DoP: BWM-LE-007
Onay	DoP: BWM-LE-008
Malzeme	Alüminyum, EPDM conta
